Shenzhen Hanxia Electronics Co., LTD


LA16-11Z 5A 30VDC/3A 250VAC 3 pin switch ON OFF stop switch red head push button emergency switch
Current Location:HOME > PRODUCTS > Button Switch >

Short Description:

Product description
Item name: emergency mushroom push button switch
Model:LA16-11Z
Rating: 3A 250V AC
Contact resistance: ≤50mΩ
Insulation resistance: ≥100mΩ
Dielectric strength: 1500V


PRODUCT DETAIL


Quick Details


  • Certification:

  • CE


  • Whether the smart:

  • No
  • Place of Origin:

  • Guangdong, China
  • Brand Name:

  • OEM/HANXIA
  • Model Number:

  • LA16-11Z
  • Protection Level:

  • IP40
  • Max. Current:

  • 3A/5A
  • Max. Voltage:

  • 250V AC/30V DC
  • LED:

  • Yes
  • Item name:

  • 3 pin switch emergency stop switch
  • Mounting hole size:

  • Dia 16mm
  • Material of contact type:

  • Silver alloy contact
  • Material of shell:

  • Flame retarding material
  • Contact Type:

  • 1NO1NC
  • Action Type:

  • Maintained/latching/self-locking
  • Keyword 1:

  • emergency stop switch
  • Keyword 2:

  • panel mounting button switch
  • Keyword 3:

  • emergency stop button switch

    Product Name

    3 pin switch emergency stop switch

    Model

    LA16-11Z

    Cycle

    100000 cycles

    operating force

    800-2000gf

    temperature

    -20℃-+55℃

    voltage rating

    AC 250V /DC 30V

    rated current

    AC 3A /DC 5A

    Certification

    ROHS

    Advantage

    Quality guarantee, 100% pre-test for each emergency stop button switch.


图片3图片4 主图1 主图5
