KA7-11/12FLN Mini Red Self-locking Touch On/Off Switch ip65 2 pins Push Button Switch
Current Location:HOME > PRODUCTS > Button Switch >

Short Description:

Product description
Item name: press button  switch KA7-1112FLN
Rating: 3A 250V AC
Contact resistance: ≤50mΩ
Insulation resistance: ≥100mΩ
Insolation strength:1000VAC(50hz/1min)
Operating temperature:-20℃~55℃
Electrical life:>50,000 cycles
Mechanical life:>100,000 cycles
Waterproof code:IP67


PRODUCT DETAIL


Quick Details


  • Certification:

  • ROHS


  • Place of Origin:

  • Guangdong, China
  • Brand Name:

  • hanxia
  • Model Number:

  • KA7-1112FLN
  • Protection Level:

  • Ip65
  • Max. Current:

  • 0.1A
  • Max. Voltage:

  • 250VAC
  • LED:

  • Other
  • Item name:

  • KA7-1112FLN Mini Red Self-locking Touch On/Off Switch
  • Rating:

  • 3A 250VAC
  • Insulation resistance:

  • 100MΩ min.500VDC
  • Dielectric resistance:

  • 250V AC for 1min
  • Contact resistance:

  • 50MΩ Max
  • Operating temp.range:

  • -25℃ to +55℃
  • Lifetime:

  • Electrical life:>50,000 cycles
    Mechanical life:>100,000 cycles
  • Operating force:

  • 4N~7N
  • Type:

  • Push button switch
  • Product Name

    KA7-1112FLN Mini Red Self-locking Touch On/Off Switch ip65 2 pins Push Button Switch

    Model

    KA7-112FLN

    Color selection

    red

    operating force

    4N~7N

    temperature

    -25℃~+55℃

    voltage rating

    250V

    rated current

    3A

    Contact form

    self-centering/NO NC

    supply ability

    We are one of the top ten switch socket suppliers in mainland China
