Quick Details

• Model Number:

• Type C 14pin side plug

• Type:

• USB Type C

• Place of Origin:

• China

• Item name:

• usb3.1 type-c 14pin connector

• Current Rating:

• 5A

• Voltage Rating:

• 20V DC

• Operation Temperature:

• -30℃ ~ +85℃

• Operating:

• 10000 cycles

• Usage:

• Use for pcb board

  Product Name	High quality high current side insert female jack double row 14pin side plug usb3.1 type-c 14pin connector
  Life	≥10,000 cycles
  Insulation resistance	100mΩ Min
  Contact resistance	40mΩ Max
  Temperature	-30℃  to +85℃
  Rated Voltage	20V Max
  Rated current	5A Max
