Product description
Item name: SKPMAPE010 6*6 silent tact switch EOPASACIA
Model No.: TS665WS
Cycle:300,000 cycles(max)
Certificate:ROHS,CE
temperature:-20℃—+85℃
Size:6*6*5mm
| Product Name | SKPMAPE010 6*6 silent tact switch EOPASACIA |
| Size | 6*6*5mm |
| Max. Current | 50mA |
| Max. Voltage | 12V DC |
| operation force | 250±50gf |
| Operation temp | -20-85℃ |
| Model | TS665WS |
| Material | Plastic |
| Withstand Voltage | AC250V(50Hz)/min |
| Insulation Resistance | ≥100mΩ |
| Contact Resistance | ≤200mΩ |
